Circular Chut Blockage Switch
Working principle:
1. The detector adopts the pressure measuring activity structure, after troubleshooting, the thrust of the pressure spring makes it
automatically reset.
2. High-performance micro switch is used in the machine, the action is flexible, high reliability.
3. Small size, easy to install.
Installation and use:
Installed on the vertical sympathetic wall of the slot which is not directly impacted by the moving material.
Product can be divided into two groups, installation height according to user needs, generally installed in the bottom of the chute in the
upper third of the height is appropriate.
The product can also be used in two groups of four, one group is installed on the side wall of the chute at a relative height of one-third from
the bottom, as a light blockage detection, used to receive the signal from the grasping device, when the chute is blocked, the signal is received
by the moving device and starts to vibrate, the other group is installed at the bottom two-thirds, as a heavy blockage detection output stop signal
when blockage occurs.
Technical indicators:
| Item | Parameters |
| Model | Chute Blockage Switch |
| Ambient temperature | -20℃-+40℃ |
| Relative humidity | ≥85% |
| Movement Angle | 5° |
| Limit Angle | 10° |
| Number of contacts | 1NO 1NC |
| Contact Capacity | AC380V 5A |
